USB 2 Extension System

2-port USB 2.0, CAT 5e/6 Point-to-Point Extension System with Flexible Power

USB 2 Extension System
No image available

Product Overview

The USB 2ES enables connection of up to the full 480Mbps speeds of USB 2.0 as well as USB 1.1 devices for up to 100 meters (328 ft.) over a single CAT 5e/6 Ethernet cable. Unlike other USB 2.0 extension devices, the USB 2ES supports all transaction types and is capable of supporting uncompressed HD video over USB. The USB 2ES also includes flexible power that allows the convenience of only needing to power one side (Local or Remote).  Providing more flexible, accessible and/or hidden placement of devices, the dual-port USB extender is great for video cameras, microphones, speakers, flash drives, hard drives, or any other USB 2.0 or 1.1 device.

Features and Benefits

  • Extend devices up to 100m (328 ft) over a single CAT 5e/6 cable.
  • Supports up to two (2) USB 2.0 or 1.1 devices up to 480 Mbps.
  • Supplies up to 1.5A total when both USB ports are in use.
  • Supports all classes and endpoint types (Iso, Bulk, Interrupt, & Control)
  • Provides mass storage acceleration for USB device bulk transfers.
  • True plug and play; no software drivers required.
  • Works with all major operating systems (Windows®, macOS™, Linux®, Chrome OS™).
  • Slim and rugged aluminum metal enclosure
  • FCC/CE Class B certification

Application Example

USB 2 Extension System

 Performance:

  • USB Bandwidth: USB 2.0 up to 480 Mbps and USB 1.1 up to 12 Mbps
  • Available Power at Remote Extender: Up to 1A per USB port, 1.5A total shared
  • Maximum Extension Range: Up to 100m (328ft) over solid core CAT 5e/6 ethernet cabling

Mechanical:

  • USB Ports, Local Extender: 1x USB 2, Type-B
  • USB Ports, Remote Extender: 2x USB 2, Type-A
  • Ethernet Ports: 1x RJ45 Ethernet link port for Local to Remote Extender
  • Power Supply (used at either Local or Remote extender): 100-240V AC Input, 24V 1A DC Output
  • Dimensions: 3.4" x 3.0" x 1.0" (8.7cm x 7.5cm x 2.6cm)
  • Operating Temp/Humidity: Operating: 32°F - 122°F (0°C – 50°C), 20-80% RH non-condensing
  • Includes mounting plate built into base

Compliance:

  • FCC (Class B), CE (Class B)
  • Environmental: RoHS2 (CE)

Warranty

  • 2 years
  • 1x Local Extender
  • 1x Remote Extender
  • 1x 6 ft. (2M) USB Cable, A to B
  • 1x Power Adapter
  • Video conferencing
  • Security Camera monitoring and control
  • Medical Device Connectivity
  • KVM (Keyboard, Video, Mouse) extension
  • Remote storage
